High-Performance Liquid Barrier

Custom Spout Pouches:Smarter Liquid & Paste Packaging

Move from heavy rigid bottles to high-barrier flexible pouches that stop waste. Built to pour perfectly, block leaks, and give your brand more space to stand out. Ideal for wholesale liquid packaging bags and configured as premium stand up spouted pouches for commercial applications.

Liquid Safety Specs

100% Leak-Proof Seal Hot-Fill & Pasteurization Ready Up to 85% Plastic Reduction
Custom Spout Pouches
Cost & Structural Benefits

Key Advantages: Why Brands Choose Custom Spout Pouches Over Rigid Bottles

Moving to flexible spouted pouches does more than look good. It helps you get every drop of product out, cuts your shipping costs, and stops damage in transit using eco-friendly materials.

99%Evacuation Rate

Get 99% of Your Product Out

Stop wasting product. The flexible design lets your customers squeeze out almost every drop of thick liquids, purees, or cosmetics. This keeps them happy and beats stiff plastic pumps.

Low WasteBetter Yield
80%Volume Reduct.

Cut Freight & Storage by 80%

We ship and store them flat before filling. One truck of empty spout pouches holds as much as 25 trucks of rigid plastic bottles. This saves you big money on shipping.

Shipping Ratio1-to-25 Space Savings
0%Transit Breakage

Built Tough to Block Damage

Stop worrying about broken bottles. We use strong barrier layers and tough nylon cores so these pouches handle hard drops and pressure changes without cracking or leaking.

Tough CoreNylon Shield
Custom Options

Build Your Custom Spout Pouch Specs

Choose the right diameter, cap, and inner lining to match your liquid perfectly. Make your brand stand out with digital printing, gravure printing, and finishes like matte varnish, spot UV, and holographic effects.

SCALE: 1.25 / CAD-ACTIVE
SYSTEM: 3-STAGE EVAC
HOTSPOT AUTOFOCUS
ALIGNMENT RIDGE // Ø 8.5-22mm
TAMPER SEAL // ANTI-SWALLOW
3-LAYER LAMINATE // CO-EXTRUDED
Dispensing Technology

Smart Necks & Spouts

Pick from 8.5mm to 22mm inner widths. We build them with ridges that lock into your high-speed filling lines to stop spinning and spills.

Engineering Specs Available

8.5mm - 22mm Variable Calibers
Anti-Rotation Dual-Ridge Flanges
FFS High-Speed Rail Calibration
PP / PE Food-Grade Polymers
Size & Flow Guide

Sizes & Capacities for Custom Spout Pouches

Match your liquid volume to our standard sizes. We can also build custom shapes to fit your exact needs.

3D Dimensional CAD Blueprint
ACTIVE: 250 ml / 8.5 oz
CENTER DIVIDERFRONT VIEWH:170mmW:110mmSpout: 10mmSIDE VIEWG:35mm
Active Specs Readout
250 ml / 8.5 oz
Width (W)
110mm
Height (H)
170mm
Gusset (G)
35mm
Caliber (C)
10mm
Capacity BenchmarkStandard Dimensions (W x H + G)Recommended Spout CaliberPrimary Fluid Target
100 ml / 3.4 oz80mm x 130mm + 25mm
8.5mmCorner or Center
Energy Gels, Cosmetic Serums, Travel Packs
250 ml / 8.5 oz
110mm x 170mm + 35mm
10mmCenter Top
Baby Food Purees, Fruit Juices, Yogurt Slurries
500 ml / 16.9 oz140mm x 210mm + 40mm
15mmCenter Top
Cold-Brew Coffee, Craft Cocktails, Hand Soap
1000 ml / 33.8 oz160mm x 270mm + 45mm
15mm / 22mmCenter
Laundry Detergent Refills, Automotive Fluid, Sauces

Liquid Thickness & Spout Guide

How fast your product pours depends on its thickness and the spout size. Thin liquids like serums and gels work well with 8.5mm or 10mm spouts. Thick liquids like laundry gels, sauces, or yogurt need 15mm or 22mm spouts so they fill quickly on your line.

Industry Uses

How Different Industries Use Custom Spout Pouches

See how top brands use our spout pouches to pack everything from hot-filled drinks to thick gels.

01Functional Beverages & Cold-Brew

Beverage Packaging: Lock In Flavor

Strong foil layers block oxygen to protect cold-brews, energy gels, premium juices, and alcohol. They hold up to hot-filling at 90°C (194°F).

Beverage Packaging: Lock In Flavor
Barrier CoreMetallic Co-Extrusion
Thermal RangePasteurization up to 90°C
02Organic Purees & Baby Food

Baby Food & Puree: Clean and Safe

100% BPA-free and safe for food. We build these with corner spouts to easily squeeze out purees, soups and sauces. They come with child-safe caps.

Baby Food & Puree: Clean and Safe
Safety Standard100% BPA-Free / FDA Approved
Spout ErgonomicsCorner-Fit Controlled Squ.
03Personal Care & Eco-Refills

Personal Care Refills: Save Plastic

A better choice than heavy jugs for shampoo, hand soap, and body wash. You cut plastic use by up to 85% and get a package that looks great on the shelf.

Personal Care Refills: Save Plastic
Plastic SavingsUp to 85% Weight Reduct.
Dispense SystemAnti-Drip Resealable Valve
04Automotive & Industrial Fluids

Industrial Fluids: Tough Chemical Protection

We use strong polymers built to hold motor oils, screen washes, and liquid detergents safely. They won't leak or puncture when dropped.

Industrial Fluids: Tough Chemical Protection
Polymer BlendHigh-Tensile Polyolefins
Impact Standard1.8m Drop Resistance
Quality Check

Quality Shield:
Zero-Leak Quality Checks for Spout Pouches

Liquid packaging must not leak. We test every batch hard and manage delivery to your door so your food or chemical packaging arrives ready to fill.

Hard Testing to Stop Leaks

We test every batch with high pressure and vacuum checks. We make sure the side seals and spout joints hold strong under heavy cargo pressure so they never leak.

Hydro-Burst Safe≤0.01% Defect Rate

Safe and Tested Materials

Approved for FDA and EU food contact. We leave no solvents, heavy metals, or phthalates behind. This keeps your liquid's taste, smell, and quality exactly how you made it.

FDA / EU Food GradeSGS Audited

Easy Global DDP Shipping

Liquid packaging gets heavy. We handle all the shipping, customs, and import taxes for you. Your pouches arrive directly at your loading dock.

DDP Import HandledTo-Door Delivery
Technical FAQ

Technical FAQ: Custom Spout Pouches

Get answers on specs, heat limits, shipping, and testing for bulk spout pouches.

We build our spouts with standard neck sizes and holding rails. This helps them fit right into your rotary or inline filling machines. We send you physical samples first so you can test them on your line. Request a free sample today to check the fit.
Yes. If you hot-fill organic juices or sauces, we use heat-resistant RCPP layers and strong glue on various plastic films. This setup handles temperatures up to 90°C (194°F) without breaking down or leaking.
The spot where the spout meets the film takes the most stress. We use a two-step heat welding process that melts the spout base and film together into one solid piece. We also pack your orders in strong export cartons with corner guards to block damage when stacked.
It is critical to test thick fluids, cosmetics, or chemicals that might break down a pouch. We send you blank sample pouches made with different materials. Your lab can run tests to see how they hold up before you pay for printing and foil stamping.

Ready to Create Your Custom Spout Pouches?

Get in touch with our packaging experts today to discuss your requirements and receive a customized quote for your brand.
